LGW2G271MELZ50

270uF ±20% 400V 1680mA Φ22mm

270 µF 400 V Aluminum Electrolytic Capacitors Radial, Can - Snap-In - 3000 Hrs @ 105°C

立创商城:
270uF ±20% 400V

得捷:
CAP ALUM 270UF 20% 400V SNAP

艾睿:
If you need to filter lower signal frequencies, then this electrolytic LGW2G271MELZ50 aluminum capacitor, developed by Nichicon, is the tool you need. It can withstand a voltage of 400 VDC. This aluminum electrolytic capacitor has a maximum operating temperature of 105 °C. This product is 50 mm tall with a diameter of 22 mm. This part has a lead diameter of 0.8 mm and a pitch of 10 mm. It has a tolerance of 20%. Its leakage current is 980@5Min μA. Its capacitance value is 270uF. The LGW2G271MELZ50 aluminum electrolytic capacitor has a snap-in termination style.

TME:
Capacitor: electrolytic; THT; 270uF; 400VDC; Ø22x50mm; ±20%; 3000h
