Description
The LT®1460 is a micropower bandgap reference that combines very high accuracy and low drift with low power dissipation and small package size. This series reference uses curvature compensation to obtain low temperature coefficient and trimmed precision thin-film resistors to achieve high output accuracy. The reference will supply up to 20mA with excellent line regulation characteristics, making it ideal for precision regulator applications.
Features
Trimmed to High Accuracy: 0.075% Max
Low Drift: 10ppm/°C Max
Industrial Temperature Range
Temperature Coefficient Guaranteed to 125°C
Low Supply Current: 130µA Max LT1460-2.5
Minimum Output Current: 20mA
No Output Capacitor Required
Reverse Battery Protection
Minimum Input/Output Differential: 0.9V
Available in S0-8, MSOP-8, PDIP-8, TO-92 and SOT- 23 Package
