LINEAR TECHNOLOGY LTC3255HDD#PBF 芯片, 降压电荷泵, 500KHZ, DFN-10
The is a switched-capacitor step-down DC/DC charge-pump Converter that produces a regulated output from a 4 to 48V input. In applications where the input voltage exceeds twice the output voltage, 2:1 capacitive charge-pumping extends output current capability beyond input supply current limits. At no load, Burst Mode® operation cuts VIN quiescent current to 16µA. With its integrated VIN shunt regulator, the LTC3255 excels in 4 to 20mA current loop applications. The device enables current multiplication of 4mA input current can power a 7.4mA load continuously. Alternatively, the LTC3255 serves as a higher efficiency replacement for linear regulators and provides a space-saving inductor-free alternative to buck DC/DC converter. The LTC3255 withstands reverse-polarity input supplies and output short-circuits without damage. Safety features including current limit and over temperature protection further enhance robustness.
输出接口数 1
输出电压 2.4V ~ 12.5V
输出电流 50 mA
针脚数 10
开关频率 500 kHz
输入电压Max 48 V
输入电压Min 4 V
输出电压Max 12.5 V
输出电压Min 2.4 V
工作温度Max 150 ℃
工作温度Min -40 ℃
输入电压 4V ~ 48V
安装方式 Surface Mount
引脚数 10
封装 DFN-10
封装 DFN-10
工作温度 -55℃ ~ 150℃ TJ
产品生命周期 Unknown
包装方式 Cut Tape CT
制造应用 Power Management, 电源管理, 通信与网络, Automation & Process Control, 自动化与过程控制, Communications & Networking, 传感与仪器, Sensing & Instrumentation
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC标准 No SVHC
REACH SVHC版本 2015/12/17
ECCN代码 EAR99
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
LTC3255HDD#PBF Linear Technology 凌力尔特 | 当前型号 | 当前型号 |
LTC3255HDD#TRPBF 凌力尔特 | 完全替代 | LTC3255HDD#PBF和LTC3255HDD#TRPBF的区别 |
LTC3255IDD#PBF 凌力尔特 | 类似代替 | LTC3255HDD#PBF和LTC3255IDD#PBF的区别 |
LTC3255EDD#PBF 凌力尔特 | 类似代替 | LTC3255HDD#PBF和LTC3255EDD#PBF的区别 |
