LINEAR TECHNOLOGY LT3511EMS#PBF DC-DC Switching Regulator, Adjustable, 4.5V-100Vin, 1.23V/240mA out, 650kHz, MSOP-16
Do you have to step up or down from one voltage level to another? The flyback DC voltage controller gives you the ability to do just that. This DC voltage controller has single output. This DC voltage controller has an input voltage of 4.5 to 100 V. It has a switching frequency of 650Typ kHz. This DC voltage controller has a minimum operating temperature of -40 °C and a maximum of 125 °C.
输出接口数 1
输出电压 ≥1.23 V
输出电流 240 mA
开关频率 650 kHz
输入电压Max 100 V
输入电压Min 4.5 V
输出电压Min 1.23 V
工作温度Max 125 ℃
工作温度Min -40 ℃
输入电压 4.5V ~ 100V
安装方式 Surface Mount
引脚数 16
封装 MSOP-16
高度 0.86 mm
封装 MSOP-16
工作温度 -40℃ ~ 125℃ TJ
产品生命周期 Unknown
包装方式 Tube
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC版本 2015/12/17
| 型号/品牌 | 代替类型 | 替代型号对比 |
|---|---|---|
LT3511EMS#PBF Linear Technology 凌力尔特 | 当前型号 | 当前型号 |
LT3511EMS#TRPBF 凌力尔特 | 完全替代 | LT3511EMS#PBF和LT3511EMS#TRPBF的区别 |
