LT1073CS8

Micropower DC-DC Converter Adjustable and Fixed 5V, 12V

DESCRIPTION

The LT®1073 is a versatile micropower DC/DC converter. The device requires only three external components to deliver a fixed output of 5V or 12V. The very low minimum supply voltage of 1V allows the use of the LT1073 in applications where the primary power source is a single cell. An on-chip auxiliary gain block can function as a low battery detector or linear post-regulator.

FEATURES

■ No Design Required

■ Operates at Supply Voltages from 1V to 30V

■ Consumes Only 95µA Supply Current

■ Works in Step-Up or Step-Down Mode

■ Only Three External Off-the-Shelf Components Required

■ Low-Battery Detector Comparator On-Chip

■ User-Adjustable Current Limit

■ Internal 1A Power Switch

■ Fixed or Adjustable Output Voltage Versions

■ Space-Saving 8-Pin PDIP or SO-8 Package

APPLICATIONS

■ Pagers

■ Cameras

■ Single-Cell to 5V Converters

■ Battery Backup Supplies

■ Laptop and Palmtop Computers

■ Cellular Telephones

■ Portable Instruments

■ 4mA to 20mA Loop Powered Instruments

■ Hand-Held Inventory Computers

■ Battery-Powered α, β, and γ Particle Detectors
