LM25576 / LM25576 -Q1 SIMPLE SWITCHER 42V , 3A降压型开关稳压器 LM25576/LM25576-Q1 SIMPLE SWITCHER 42V, 3A Step-Down Switching Regulator
Buck Switching Regulator IC Positive Adjustable 1.225V 1 Output 3A 20-PowerTSSOP 0.173", 4.40mm Width
得捷:
IC REG BUCK ADJ 3A 20HTSSOP
立创商城:
降压型
贸泽:
Switching Voltage Regulators R 926-LM25576MHX/NOPB
艾睿:
Adjust the voltage level of your devices with this step down LM25576MHX DC to DC converter from Texas Instruments. This converter&s;s single output can produce a current up to 3 A. This will operate at a minimum voltage of 6 V and a maximum voltage of 42 V, making it easy to control the power in your circuit. With an adjustable output that has a voltage of 1.225 to 40 V, this is power management at its best. This converter is 91 % efficient. You can operate this at a switching frequency of 50 to 1000 kHz. Tape and reel packaging will encase this product during shipment, in order to ensure safe delivery and enable quick mounting of components. This converter has an operating temperature range of -40 °C to 125 °C.
Chip1Stop:
Conv DC-DC Single Step Down 6V to 42V 20-Pin HTSSOP EP T/R
Verical:
Conv DC-DC 6V to 42V Step Down Single-Out 1.225V to 40V 3A 20-Pin HTSSOP EP T/R
Win Source:
42V, 3A Step-Down Switching Regulator
输出接口数 1
输出电压 1.225V ~ 40V
输出电流 3 A
静态电流 1.00 mA
调节输出数 1
开关频率 50kHz ~ 1MHz
拓扑结构 Buck
输入电压Max 42 V
输入电压Min 6 V
输出电压Max 40 V
输出电压Min 1.225 V
输出电流Max 3 A
工作温度Max 125 ℃
工作温度Min 40 ℃
输入电压 6V ~ 42V
安装方式 Surface Mount
引脚数 20
封装 TSSOP-20
封装 TSSOP-20
工作温度 -40℃ ~ 125℃ TJ
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 Non-Compliant
含铅标准 Contains Lead
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
LM25576MHX TI 德州仪器 | 当前型号 | 当前型号 |
LM25576MH/NOPB 德州仪器 | 类似代替 | LM25576MHX和LM25576MH/NOPB的区别 |
LM25576MHX/NOPB 德州仪器 | 类似代替 | LM25576MHX和LM25576MHX/NOPB的区别 |
LM25576MH 德州仪器 | 类似代替 | LM25576MHX和LM25576MH的区别 |
