LM25066APSQE/NOPB 编带
基站网络线路卡,服务器 PMIC 24-WQFN(4x5)
得捷:
IC CTLR PM HOTSWAP 24WQFN
欧时:
LM25066APSQE/NOPB, Voltage Controller
立创商城:
LM25066APSQE/NOPB
德州仪器TI:
2.9-V to 17-V hot swap controller with I2C and PMBus with increased monitoring accuracy
贸泽:
热交换电压控制器 System Pwr Mgmt & Protect IC w/ PMBus
艾睿:
Use this power management ic LM25066APSQE/NOPB charge controller from Texas Instruments to control the environment of your batteries. With an output that has a voltage of 2.9 to 17 V, this is power management at its best. This component will be shipped in tape and reel packaging for effective mounting and safe delivery. This device has a minimum operating supply voltage of 2.9 V and a maximum of 17 V. This battery gauge has a minimum operating temperature of -40 °C and a maximum of 125 °C.
安富利:
Power Management IC 2.9V to 17V 24-Pin LLP EP T/R
Chip1Stop:
Power Management IC 2.9V to 17V 24-Pin WQFN EP T/R
Verical:
Hot Swap Controller 1-CH 17V N-Channel Positive Voltage 24-Pin WQFN EP T/R
Newark:
# TEXAS INSTRUMENTS LM25066APSQE/NOPB Hot Swap Controller, 2.9V to 5.5V supply, WQFN-24
DeviceMart:
IC CTLR PM HOTSWAP 24-LLP
Win Source:
IC CTLR PM HOTSWAP 24WQFN
电源电压DC 2.90V min
输出接口数 1
输入电压DC 17.0 V
输出电压 2.9V ~ 17V
供电电流 5.8 mA
工作温度Max 125 ℃
工作温度Min -40 ℃
电源电压 2.9V ~ 17V
电源电压Max 5.5 V
电源电压Min 2.9 V
输入电压 17 V
安装方式 Surface Mount
引脚数 24
封装 WQFN-24
封装 WQFN-24
工作温度 -40℃ ~ 85℃
产品生命周期 Active
包装方式 Tape & Reel TR
制造应用 基站网络线路卡,服务器
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC标准 No SVHC
REACH SVHC版本 2015/06/15
ECCN代码 EAR99
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
LM25066APSQE/NOPB TI 德州仪器 | 当前型号 | 当前型号 |
LM25066APSQX/NOPB 德州仪器 | 完全替代 | LM25066APSQE/NOPB和LM25066APSQX/NOPB的区别 |
LM25066APSQ/NOPB 德州仪器 | 类似代替 | LM25066APSQE/NOPB和LM25066APSQ/NOPB的区别 |
