LP3855ES-2.5/NOPB

具有使能功能的 1.5A、7V、超低压降稳压器 5-DDPAK/TO-263 -40 to 125

PMIC - 稳压器 - 线性 正 固定 1 输出 1.5A DDPAK/TO-263-5

得捷:
IC REG LIN POS ADJ 1.5A DDPAK

立创商城:
LP3855ES-2.5/NOPB

德州仪器TI:
1.5-A, 7-V, ultra-low-dropout voltage regulator with enable

艾睿:
Stable voltages are always needed for sensitive systems implement this LDO LP3855ES-2.5/NOPB linear regulator from Texas Instruments. Its typical dropout voltage at current is 0.024@150mA|0.24@1.5A V. It has an overall accuracy of ±1.5 %. This voltage regulation device&s;s single output can produce a current up to 1.5 A. The best way to provide power to your application is by using this, which needs a voltage of at least 2.5 V and no higher than 7 V. With a fixed output that has a voltage of 2.5 V, this is power management at its best. Operate at a constant current by utilizing the load regulation of 0.06%Typ and line regulation of 0.02%Typ. In order to ensure parts aren&s;t damaged by bulk packaging, this product comes in tube packaging to add a little more protection by storing the loose parts in an outer tube. Its polarity is positive. This voltage regulation device has an operating temperature range of -40 °C to 125 °C. The maximum dropout voltage is 0.035@150mA|0.28@1.5A V.

安富利:
LDO Regulator Pos 2.5V 1.5A 6-Pin5+Tab TO-263 Rail

Chip1Stop:
LDO Regulator Pos 2.5V 1.5A 6-Pin5+Tab TO-263 Rail

Verical:
LDO Regulator Pos 2.5V 1.5A 6-Pin5+Tab TO-263 Tube

DeviceMart:
IC REG LDO 2.5V 1.5A TO-263-5
