LT1085CM#PBF

LINEAR TECHNOLOGY  LT1085CM#PBF  电压稳压器, LDO, 可调, 2.6V至30V输入, 1.3V压差, 25V/3A输出, TO-263-3

The is a low-dropout Positive Adjustable Regulator designed to provide 7.5/5/3A with higher efficiency than currently available devices. All internal circuitry is designed to operate down to 1V input-to-output differential and the dropout voltage is fully specified as a function of load current. Dropout is guaranteed at a maximum of 1.5V at maximum output current, decreasing at lower load currents. On-chip trimming adjusts the reference voltage to 1%. Current limit is also trimmed, minimizing the stress on both the regulator and power source circuitry under overload conditions. This device is pin compatible with older 3-terminal regulators. A 10µF output capacitor is required on this device. However, this is included in most regulator designs. Unlike PNP regulator, where up to 10% of the output current is wasted as quiescent current.

.

Guaranteed dropout voltage at multiple current levels

.

Operates down to 1V dropout

.

0.015% Line regulation

.

0.1% Load regulation

.

100% Thermal limit functional test
