LP3883ES-1.2

TEXAS INSTRUMENTS  LP3883ES-1.2  固定电压稳压器, LDO, 1.42V至5.5V, 210mV压差, 1.2V输出, 3A输出, TO-263-5

The is a 1.2V fixed output fast response ultra-low-dropout LDO Linear Regulator which can maintain output voltage regulation with minimum input to output voltage drop. Fabricated on a CMOS process, the device operates from two input voltages, Vbias provides voltage to drive the gate of the N-MOS power transistor, while Vin is the input voltage which supplies power to the load. The use of an external bias rail allows the part to operate from ultra-low Vin voltages. Unlike bipolar regulators, the CMOS architecture consumes extremely low quiescent current at any output load current. The use of an N-MOS power transistor results in wide bandwidth, yet minimum external capacitance is required to maintain loop stability. The fast transient response of these devices makes them suitable for use in powering DSP, microcontroller core voltages and switch mode power supply post regulators.

.

Low ground pin current

.

60nA Quiescent current in shutdown typical

.

0.04%/A Load regulation

.

1.5% Output accuracy 25°C

.

Overtemperature and overcurrent protection
