LTC3814EFE-5#PBF

LINEAR TECHNOLOGY  LTC3814EFE-5#PBF  直流/直流控制器, 电流模式, 4.35V至14V, 1路输出, 同步升压, 1MHz, TSSOP-16

The is a synchronous step-up Switching Regulator Controller can generate output voltages up to 60V. The LTC3814-5 uses constant off-time peak current control architecture to deliver very high duty cycles with accurate cycle-by-cycle current limit without requiring a sense resistor. A precise internal reference provides ±0.5% DC accuracy. A high bandwidth 25MHz error amplifier provides very fast line and load transient response. Large 1R gate drivers allow the LTC3814-5 to drive large power MOSFETs for higher current applications. The operating frequency is selected by an external resistor and is compensated for variations in VIN. A shutdown pin allows the LTC3814-5 to be turned off reducing the supply current to <230µA.

.

Large 1R Gate drivers

.

No current sense resistor required

.

Dual N-channel MOSFET synchronous drive

.

±0.5% 0.8V Voltage reference

.

Fast transient response

.

Programmable soft-start

.

Generates 5.5V Driver supply

.

Power good output voltage monitor

.

Adjustable cycle-by-cycle current limit

.

Undervoltage lockout on driver supply

.

Output overvoltage protection
