LM2670 SIMPLE SWITCHER高效率3A降压型稳压器具有同步 LM2670 SIMPLE SWITCHER High Efficiency 3A Step-Down Voltage Regulator with Sync
Buck Switching Regulator IC Positive Adjustable 1.2V 1 Output 3A TO-263-8, D²Pak 7 Leads + Tab, TO-263CA
得捷:
IC REG BUCK ADJ 3A TO263-7
艾睿:
Adjust the voltage level of your devices with this step down LM2670S-ADJ DC to DC converter from Texas Instruments. This converter&s;s single output can produce a current up to 3 A. Supply your circuit with sufficient power by implementing this, which requires a minimum input voltage of 8 V that does not exceed 40 V. With an adjustable output that has a voltage of 1.2 to 37 V, this is power management at its best. This converter is 88typ % efficient. Its switching regulator has a frequency of 260Typ kHz. In order to ensure parts aren&s;t damaged by bulk packaging, this product comes in tube packaging to add a little more protection by storing the loose parts in an outer tube. This converter has an operating temperature range of -40 °C to 125 °C.
Chip1Stop:
Conv DC-DC 8V to 40V Step Down Single-Out 1.2V to 37V 3A 8-Pin7+Tab TO-263 Tube
Verical:
Conv DC-DC 8V to 40V Step Down Single-Out 1.2V to 37V 3A 8-Pin7+Tab TO-263 Tube
频率 260 kHz
电源电压DC 40.0V max
额定电流 3.00 A
输出接口数 1
输出电压 1.2V ~ 37V
输出电流 3 A
静态电流 4.20 mA
调节输出数 1
开关频率 260 kHz
拓扑结构 Buck
输入电压Max 40 V
输入电压Min 8 V
输出电压Max 37 V
输出电压Min 1.2 V
输出电流Max 3 A
工作温度Max 125 ℃
工作温度Min -40 ℃
输入电压 8V ~ 40V
安装方式 Surface Mount
引脚数 7
封装 TO-263-8
封装 TO-263-8
工作温度 -40℃ ~ 125℃ TJ
产品生命周期 Active
包装方式 Cut Tape CT
RoHS标准 Non-Compliant
含铅标准 Contains Lead
REACH SVHC版本 2015/06/15
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
LM2670S-ADJ TI 德州仪器 | 当前型号 | 当前型号 |
LM2670S-ADJ/NOPB 德州仪器 | 功能相似 | LM2670S-ADJ和LM2670S-ADJ/NOPB的区别 |
