LTC3108IGN-1#PBF

LINEAR TECHNOLOGY  LTC3108IGN-1#PBF  芯片, 升压稳压器, 0.5V输入, 可选输出, 16SSOP

The is a highly integrated DC/DC Converter ideal for harvesting and managing surplus energy from extremely low input voltage sources such as TEGs thermoelectric generators, thermopiles and small solar cells. The step-up topology operates from input voltages as low as 20mV. Using a small step-up transformer, the LTC3108-1 provides a complete power management solution for wireless sensing and data acquisition. The 2.2V LDO powers an external microprocessor, while the main output is programmed to one of four fixed voltages to power a wireless transmitter or sensors. The power good indicator signals that the main output voltage is within regulation. A second output can be enabled by the host. A storage capacitor provides power when the input voltage source is unavailable. Extremely low quiescent current and high efficiency design ensure the fastest possible charge times of the output reservoir capacitor.

.

Power good indicator

.

Uses compact step-up transformers
