LINEAR TECHNOLOGY LT1461BCS8-2.5#PBF 电压基准, 精准微功率, 低压降, 系列 - 固定, LT1461系列, 2.5V, NSOIC-8
Even in the event of large power supply variations, this voltage reference power management device from can produce and maintain a precise DC voltage. With an output that has a voltage of 2.5 V, this is power management at its best. It has an initial accuracy of 0.06%. With a voltage no larger than 20 V, this will supply sufficient power to your circuit. Users like the load regulation of 30ppm/mA and line regulation of 8ppm/V. This voltage reference circuit supports series topology. This voltage reference circuit has an operating temperature range of 0 °C to 70 °C. It runs with a maximum temperature coefficient of 7ppm/°C.
容差 ±0.06 %
输入电压DC 20.0V max
输出电压 2.5 V
输出电流 100 mA
供电电流 70 µA
通道数 1
针脚数 8
静态电流 50.0 µA
输入电压Max 20 V
输出电压Min 2.5 V
工作温度Max 70 ℃
工作温度Min 0 ℃
精度 ±0.06 %
输入电压 3V ~ 20V
安装方式 Surface Mount
引脚数 8
封装 SOIC-8
封装 SOIC-8
工作温度 0℃ ~ 70℃ TA
温度系数 ±7 ppm/℃
产品生命周期 Unknown
包装方式 Tube
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC标准 No SVHC
REACH SVHC版本 2015/12/17
ECCN代码 EAR99
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
LT1461BCS8-2.5#PBF Linear Technology 凌力尔特 | 当前型号 | 当前型号 |
LT1461BCS8-2.5#TRPBF 凌力尔特 | 完全替代 | LT1461BCS8-2.5#PBF和LT1461BCS8-2.5#TRPBF的区别 |
