LP3853ET-2.5/NOPB

具有电源正常指示和使能功能的 3A、7V、超低压降稳压器 5-TO-220 -40 to 125

PMIC - 稳压器 - 线性 正 固定 1 输出 3A TO-220-5

得捷:
IC REG LINEAR 2.5V 3A TO220-5

立创商城:
LP3853ET-2.5/NOPB

德州仪器TI:
3-A, 7-V, ultra-low-dropout voltage regulator with power good & enable

贸泽:
LDO Voltage Regulators 3A Fast Ultra Low Dropout Linear Regulator 5-TO-220 -40 to 125

艾睿:
Maintain a steady voltage level with this LDO LP3853ET-2.5/NOPB linear regulator from Texas Instruments. Its typical dropout voltage at current is 0.039@300mA|0.39@3A V. It has an overall accuracy of ±1.5 %. This voltage regulation device&s;s single output can produce a current up to 3 A. Supply your circuit with sufficient power by implementing this, which requires a minimum input voltage of 2.5 V that does not exceed 7 V. With a fixed output that has a voltage of 2.5 V, this is power management at its best. Using a load regulation of 0.08%Typ and line regulation of 0.02%Typ is needed for a programmable DC power supply. In order to ensure parts aren&s;t damaged by bulk packaging, this product comes in tube packaging to add a little more protection by storing the loose parts in an outer tube. Its polarity is positive. The maximum dropout voltage is 0.05@300mA|0.45@3A V. This voltage regulation device has a minimum operating temperature of -40 °C and a maximum of 125 °C.

Chip1Stop:
LDO Regulator Pos 2.5V 3A 5-Pin5+Tab TO-220 Rail

Verical:
LDO Regulator Pos 2.5V 3A 5-Pin5+Tab TO-220 Tube

DeviceMart:
IC REG LDO 2.5V 3A TO-220-5
