L6226DTR

L6226 系列 双通道 全桥 驱动器 52 V 2.8 A 0.73 Ohm DMOS 表面贴装 - SOIC-24

The L6226 is a DMOS dual full bridge designed for motor control applications, realized in MultiPower-BCD technology, which combines isolated DMOS power transistors with CMOS and bipolar circuits on the same chip. Available in PowerDIP24 20+2+2, PowerSO36 and SO24 20+2+2 packages, the L6226 features thermal shutdown and a non-dissipative overcurrent detection on the high side power MOSFETs plus a diagnostic output that can be easily used to implement the overcurrent protection.

**Key Features**

.

Undervoltage lockout

.

Thermal shutdown

.

Integrated fast free wheeling diodes

.

Paralleled operation

.

Diagnostic output

.

Operating supply voltage from 8 to 52 V

.

RDSon 0.73 Ω typ. value @ TJ = 25 °C

.

2.8 A output peak current 1.4 A DC

.

Programmable high side overcurrent detection and protection

.

Cross conduction protection

.

Operating frequency up to 100 kHz
