180uF ±20% 400V 980mA Φ22mm
Since the anode is made out of pure aluminum, you"ll be able to filter lower frequencies with ease using "s electrolytic aluminum capacitor. It can withstand a voltage of 400 VDC. This aluminum electrolytic capacitor has a maximum operating temperature of 105 °C. Its capacitance value is 180uF. This part has a lead diameter of 0.8 mm and a pitch of 10 mm. This product is 45 mm tall with a diameter of 22 mm. The LGU2G181MELZ aluminum electrolytic capacitor has a snap-in termination style. It has a tolerance of 20%. Its leakage current is 800@5Min μA.
额定电压DC 400 V
工作电压 400 VDC
电容 180 µF
容差 ±20 %
产品系列 LGU
纹波电流 980 mA
纹波电流高频 980mA @120Hz
纹波电流低频 1.4014A @50kHz
工作温度Max 105 ℃
工作温度Min 25 ℃
额定电压 400 V
安装方式 Through Hole
封装 Snap-In
长度 45 mm
高度 45 mm
直径 22.0 mm
封装 Snap-In
工作温度 -25℃ ~ 105℃
产品生命周期 Active
包装方式 Bulk
最小包装 50
寿命（小时） 3000 h
制造应用 通用
RoHS标准 RoHS Compliant
含铅标准 Lead Free
ECCN代码 EAR99
| 型号/品牌 | 代替类型 | 替代型号对比 |
|---|---|---|
LGU2G181MELZ Nichicon 尼吉康 | 当前型号 | 当前型号 |
LGN2G181MELZ35 尼吉康 | 类似代替 | LGU2G181MELZ和LGN2G181MELZ35的区别 |
LAR2G181MELZ35 尼吉康 | 类似代替 | LGU2G181MELZ和LAR2G181MELZ35的区别 |
400MXC180MEFCSN22X45 Rubycon | 类似代替 | LGU2G181MELZ和400MXC180MEFCSN22X45的区别 |
