LINEAR TECHNOLOGY LTC3862HFE#PBF 直流/直流控制器, 2相, 恒频, 4V至36V, 1路输出, 升压, SEPIC, 500kHz, TSSOP-24
The is a 2-phase current-mode step-up DC/DC Controller that drives N-channel power MOSFETs. Two phase operation reduces system filtering capacitance and inductance requirements. The operating frequency can be set with an external resistor over a 75 to 500kHz range and can be synchronized to an external clock using the internal PLL. Multi-phase operation is possible using the SYNC input, the CLKOUT output and the PHASEMODE control pin allowing 2-, 3-, 4-, 6- or 12-phase operation. Other features include an internal 5V LDO with undervoltage lockout protection for the gate drivers, a precision RUN pin threshold with programmable hysteresis, soft-start and programmable leading edge blanking and maximum duty cycle.
输出接口数 1
输出电压 1.223V ~ 200V
针脚数 24
开关频率 500 kHz
占空比 96 %
输入电压Max 36 V
输入电压Min 4 V
最大占空比 0.96
工作温度Max 150 ℃
工作温度Min -40 ℃
电源电压 4V ~ 36V
电源电压Max 36 V
电源电压Min 4 V
输入电压 4V ~ 36V
安装方式 Surface Mount
引脚数 24
封装 TSSOP-24
封装 TSSOP-24
工作温度 -40℃ ~ 150℃ TJ
产品生命周期 Unknown
包装方式 Cut Tape CT
制造应用 Power Management, 通信与网络, Communications & Networking, 电源管理, 车用, Automotive
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC标准 No SVHC
REACH SVHC版本 2015/12/17
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
LTC3862HFE#PBF Linear Technology 凌力尔特 | 当前型号 | 当前型号 |
LTC3862EFE#PBF 凌力尔特 | 类似代替 | LTC3862HFE#PBF和LTC3862EFE#PBF的区别 |
LTC3862IFE#PBF 凌力尔特 | 类似代替 | LTC3862HFE#PBF和LTC3862IFE#PBF的区别 |
LTC3862HFE#TRPBF 凌力尔特 | 类似代替 | LTC3862HFE#PBF和LTC3862HFE#TRPBF的区别 |
