V-Ref Precision 5V 15mA 8Pin SOIC N
Even in the event of large power supply variations, this voltage reference power management device from can produce and maintain a precise DC voltage. Use this part at voltages lower than 40 V. With an output that has a voltage of 5 V, this is power management at its best. This voltage reference circuit supports series topology. Users like the load regulation of 6ppm/mA and line regulation of 12ppm/V. It runs with a maximum temperature coefficient of 5ppm/°C. This voltage reference circuit has an operating temperature range of 0 °C to 70 °C.
容差 ±0.05 %
输入电压DC 40.0V max
输出电压 5 V
输出电流 15 mA
供电电流 3.5 mA
通道数 1
静态电流 3.10 mA
输入电压Max 40 V
输出电压Min 5 V
输出电流Max 15 mA
工作温度Max 70 ℃
工作温度Min 0 ℃
输入电压 8V ~ 40V
安装方式 Surface Mount
引脚数 8
封装 SOIC-8
封装 SOIC-8
工作温度 0℃ ~ 70℃ TA
温度系数 ±5 ppm/℃
产品生命周期 Unknown
包装方式 Tube
RoHS标准 RoHS Compliant
含铅标准 Lead Free
ECCN代码 EAR99
| 型号/品牌 | 代替类型 | 替代型号对比 |
|---|---|---|
LT1027DCS8-5#PBF Linear Technology 凌力尔特 | 当前型号 | 当前型号 |
LT1027DCS8-5#TRPBF 凌力尔特 | 完全替代 | LT1027DCS8-5#PBF和LT1027DCS8-5#TRPBF的区别 |
