LT8610AIMSE-5#PBF

LINEAR TECHNOLOGY LT8610AIMSE-5#PBF Synchronous Buck Step Down,Switching Regulator, Fixed, 3.4V-42V In, 5V/3.5A Out, 2.2MHz, MSOP-16

The is a synchronous step-down Switching Regulator with 2.5µA quiescent current. Compared to the LT8610, they have higher maximum output currents of 3.5A and a faster minimum switch-ON time of 30ns. The LT8610A has the same low ripple burst mode performance of the LT8610. The other features of the LT8610 remain unchanged in the LT8610A series. A SYNC pin allows synchronization to an external clock. The EN/UV pin has an accurate 1V threshold for VIN undervoltage lockout or shut down. A capacitor on the TR/SS pin programs the output voltage ramp rate during startup. The PG flag signals when VOUT is within ±9% of the programmed output voltage as well as fault conditions.

.

Ultralow quiescent current Burst Mode® operation

.

Safely tolerates inductor saturation in overload

.

Accurate 1V enable pin threshold

.

Output soft-start and tracking
