Buck Switching Regulator IC Positive Adjustable 0.8V 1 Output 4A 20-TSSOP 0.173", 4.4mm Width Exposed Pad
Adjust the voltage level of your devices with this synchronous step down DC to DC converter from . This converter"s single output can produce a current up to 4 A. This will operate at a minimum voltage of 2.25 V and a maximum voltage of 5.5 V, making it easy to control the power in your circuit. With an adjustable output that has a voltage of 0.8 to 5 V, this is power management at its best. This converter is 95 % efficient. Your circuit has the capability to produce a constant current at its output by using a load regulation of 0.2% and line regulation of 0.2%/V. You can operate this at a switching frequency of 300 to 4000 kHz. This product will be shipped in tape and reel packaging to allow for quick mounting and safe delivery. This converter has an operating temperature range of -40 °C to 85 °C.
输出接口数 1
输出电压 0.8V ~ 5V
输出电流 4 A
开关频率 1 MHz
输入电压Max 5.5 V
输入电压Min 2.25 V
输出电压Max 5 V
输出电压Min 0.8 V
输出电流Max 4 A
工作温度Max 85 ℃
工作温度Min -40 ℃
输入电压 2.25V ~ 5.5V
安装方式 Surface Mount
引脚数 20
封装 TSSOP-20
封装 TSSOP-20
工作温度 -40℃ ~ 85℃ TA
产品生命周期 Unknown
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
ECCN代码 EAR99
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
LTC3414EFE#TRPBF Linear Technology 凌力尔特 | 当前型号 | 当前型号 |
LTC3414MPFE#PBF 凌力尔特 | 完全替代 | LTC3414EFE#TRPBF和LTC3414MPFE#PBF的区别 |
LTC3414EFE#PBF 凌力尔特 | 类似代替 | LTC3414EFE#TRPBF和LTC3414EFE#PBF的区别 |
LTC3414IFE 凌力尔特 | 类似代替 | LTC3414EFE#TRPBF和LTC3414IFE的区别 |
