LINEAR TECHNOLOGY LT1019IS8-2.5#PBF 电压基准, 精密, 系列, 分流, LT1019系列, 2.5V, NSOIC-8
Even in the event of large power supply variations, this voltage reference power management device from can produce and maintain a precise DC voltage. Using the part will provide the power your application needs by requiring a voltage not exceeding 40 V. With an output that has a voltage of 2.5 V, this is power management at its best. It has an initial accuracy of 0.2%. Operate at a constant current by utilizing the load regulation of 0.05mV/mA and line regulation of 3ppm/V. This voltage reference circuit supports shunt|series topology. This voltage reference circuit has a minimum operating temperature of -40 °C and a maximum of 85 °C. It runs with a maximum temperature coefficient of 20ppm/°C.
容差 ±0.2 %
输入电压DC 40.0V max
输出电压 2.5 V
输出电流 10 mA
供电电流 1.5 mA
通道数 1
针脚数 8
静态电流 1.20 mA
输入电压Max 40 V
输出电压Min 2.5 V
输出电流Max 10 mA
工作温度Max 85 ℃
工作温度Min -40 ℃
精度 ±0.2 %
输入电压 4V ~ 40V
安装方式 Surface Mount
引脚数 8
封装 SOIC-8
封装 SOIC-8
工作温度 -40℃ ~ 85℃ TA
温度系数 ±5 ppm/℃
产品生命周期 Active
包装方式 Tube
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC标准 No SVHC
REACH SVHC版本 2018/01/15
ECCN代码 EAR99
| 型号/品牌 | 代替类型 | 替代型号对比 |
|---|---|---|
LT1019IS8-2.5#PBF Linear Technology 凌力尔特 | 当前型号 | 当前型号 |
LT1019CS8-2.5#PBF 凌力尔特 | 类似代替 | LT1019IS8-2.5#PBF和LT1019CS8-2.5#PBF的区别 |
LT1019IS8-2.5#TRPBF 凌力尔特 | 类似代替 | LT1019IS8-2.5#PBF和LT1019IS8-2.5#TRPBF的区别 |
MAX6192CESA+ 美信 | 功能相似 | LT1019IS8-2.5#PBF和MAX6192CESA+的区别 |
