LED Uni-Color Green 0.3lm 525nm Chip LED 2Pin 0402 T/R
Green 532nm Indication - Discrete 2.85V 0402 1005 Metric
得捷:
LED GREEN DIFFUSED 0402 SMD R/A
艾睿:
LED Uni-Color True Green 525nm 2-Pin Chip 04021006Metric T/R
安富利:
LED Uni-Color Green 0.3lm 525nm Chip LED 2-Pin 0402 T/R
Verical:
LED Uni-Color True Green 525nm 2-Pin Chip 04021006Metric T/R
AMEYA360:
LED GREEN DIFF 0402 R/A SMD
Win Source:
LED GREEN DIFFUSED 0402 SMD R/A / Green 532nm LED Indication - Discrete 2.85V 0402 1005 Metric
正向电压 2.85 V
波长 532 nm
视角 140°, 165°
峰值波长 525 nm
测试电流 5 mA
正向电流 15 mA
正向电压Max 3.2 V
正向电流Max 15 mA
工作温度Max 85 ℃
工作温度Min -40 ℃
安装方式 Surface Mount
引脚数 2
封装公制 1005
封装 0402
长度 1 mm
宽度 0.5 mm
高度 0.35 mm
封装公制 1005
封装 0402
颜色 Green
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 无铅
ECCN代码 EAR99
