Murata 0201 LQP03TN_02 系列片状电感器LQP03TN_02 超小型薄型片式电感器,带薄膜技术结构。 提供各种电感值,可实现无调谐装配。 高频率范围时的高 Q 由于低杂散电容和窄电感分布产生的高自谐振频率可在高频电路(例如电信设备)中提供稳定的电感 ### 应用:-移动电话的高频率电路,如 PA、ANT、VCO、SAW 等。 移动电话 蓝牙 W-LAN 一般高频电路 ### SMT 0201 电感器(扼流圈)
固定器
立创商城:
12nH ±3% 700mΩ
得捷:
FIXED IND 12NH 250MA 700MOHM SMD
欧时:
### Murata 0201 LQP03TN_02 系列片状电感器LQP03TN_02 超小型薄型片式电感器,带薄膜技术结构。 提供各种电感值,可实现无调谐装配。 高频率范围时的高 Q 由于低杂散电容和窄电感分布产生的高自谐振频率可在高频电路(例如电信设备)中提供稳定的电感 ### 应用:-移动电话的高频率电路,如 PA、ANT、VCO、SAW 等。 移动电话 蓝牙 W-LAN 一般高频电路 ### SMT 0201 电感器(扼流圈)
艾睿:
Is space on a PCB a limiting factor for your electronic circuit design? Then use this rf chip LQP03TN12NH02D surface mount inductor from Murata to save valuable space. This SMD inductor has an operating temperature range of -55 °C to 125 °C. This component will be shipped in tape and reel packaging for effective mounting and safe delivery. This SMD inductor has a maximum DC current of 250m A with a maximum resistance of 700m Ohm. It has an inductance of 12n H. Its test frequency is 500M Hz, while its minimum self-resonant frequency is 2.9G Hz. It has a tolerance of 3%. This device utilizes thin film technology. This product is 0.63 mm long, 0.33 mm tall and 0.33 mm deep.
安富利:
Ind RF Chip Thin Film 12nH 3% 500MHz 12Q-Factor 250mA 0201 Paper T/R
Chip1Stop:
Inductor RF Chip Thin Film 12nH 3% 500MHz 12Q-Factor 250mA 700mOhm DCR 0201 Paper T/R
Verical:
Inductor RF Chip Unshielded Thin Film 0.012uH 3% 500MHz 12Q-Factor Non Magnetic 0.25A 0.7Ohm DCR 0201 T/R
儒卓力:
**LQP03TN 12nH 250mA 3% TFT **
Win Source:
FIXED IND 12NH 250MA 700 MOHM
额定电流 250 mA
容差 ±3 %
电感 12 nH
自谐频率 2.9 GHz
产品系列 LQP
电感公差 ±3 %
测试频率 500 MHz
电阻DC) ≤700 mΩ
工作温度Max 125 ℃
工作温度Min -55 ℃
电阻DC Max 0.7 Ω
安装方式 Surface Mount
封装 0201
长度 0.6 mm
宽度 0.3 mm
高度 0.33 mm
封装 0201
重量 0.0002 g
工作温度 -55℃ ~ 125℃
产品生命周期 Active
包装方式 Tape & Reel TR
最小包装 15000
RoHS标准 RoHS Compliant
含铅标准 Lead Free
ECCN代码 EAR99
