LQW15AN39NJ00D

Murata 0402 LQW15AN_00D 系列线绕电感器 0.01μH - 0.047μH高质量线圈电感器，设计用于 VHF 和 UHF 应用。 高谐振频率。 低容差电感值。 应用：高频率电路，用于无线电信设备，例如蓝牙、GSM、W-LAN。 ### 表面安装 0402 电感器（扼流圈）

Murata 0402 LQW15AN_00D 系列线绕器 0.01μH - 0.047μH

高质量线圈电感器，设计用于 VHF 和 UHF 应用。

高谐振频率。

低容差电感值。

应用：高频率电路，用于无线电信设备，例如蓝牙、GSM、W-LAN。

得捷:
FIXED IND 39NH 250MA 700MOHM SMD

欧时:
Murata LQW15AN_00 系列 非磁核心芯材 39 nH 绕线贴片电感器 LQW15AN39NJ00D, ±5%容差, 250mA Idc Q:25

立创商城:
39nH ±5% 700mΩ

贸泽:
Fixed Inductors 0402 39nH +/-5% DCR 0.70ohm

艾睿:
Save valuable space on a PCB with this rf chip LQW15AN39NJ00D surface mount inductor from Murata. This SMD inductor has an operating temperature range of -55 °C to 125 °C. This component will be shipped in tape and reel packaging for effective mounting and safe delivery. This device utilizes wirewound technology. This product is 1.1 mm long, 0.6 mm tall and 0.6 mm deep. This SMD inductor has a maximum DC current of 250m A with a maximum resistance of 700m Ohm. Its test frequency is 100M Hz, while its minimum self-resonant frequency is 3G Hz. It has a tolerance of 5%. It has an inductance of 39n H.

安富利:
Ind RF Chip Wirewound 39nH 5% 100MHz 25Q-Factor 250mA 0402 Paper T/R

Chip1Stop:
Inductor RF Chip Wirewound 39nH 5% 100MHz 25Q-Factor 250mA 700mOhm DCR 0402 T/R

Verical:
Inductor RF Chip Unshielded Wirewound 0.039uH 5% 100MHz 25Q-Factor Non Magnetic 0.25A 0.7Ohm DCR 0402 T/R

儒卓力:
**LQW15AN 0,039uH 250mA 5% WWT **

Win Source:
39nH Unshielded Wirewound Inductor 250mA 700 mOhm Max 0402 1005 Metric
