LQW2BAS33NJ00L

LQW2BA 系列 0805 33 nH 5 % 500 mA 非屏蔽 表面贴装 绕线电感

33nH Unshielded Wirewound Inductor 500mA 270mOhm Max 0805 2015 Metric

得捷:
FIXED IND 33NH 500MA 270MOHM SMD

艾睿:
Does your electronic circuit design require filtering, power supplies, and other similar functions? Then this rf chip LQW2BAS33NJ00L surface mount inductor from Murata is perfect for you! This SMD inductor has an operating temperature range of -55 °C to 125 °C. Tape and reel packaging will encase the product during shipment, ensuring safe delivery and enabling quick mounting of components. It has an inductance of 33n H. Its test frequency is 250M Hz, while its minimum self-resonant frequency is 2.15G Hz. It has a tolerance of 5%. This product is 2.29 mm long, 1.52 mm tall and 1.73 mm deep. This device utilizes wirewound technology. This SMD inductor has a maximum DC current of 500m A with a maximum resistance of 270m Ohm.

安富利:
Ind RF Chip Wirewound 33nH 5% 250MHz 60Q-Factor 500mA 0805 Embossed T/R

Verical:
Inductor RF Chip Unshielded Wirewound 0.033uH 5% 250MHz 60Q-Factor Non Magnetic 0.5A 0.27Ohm DCR 0805 T/R

Win Source:
33nH Unshielded Wirewound Inductor 500mA 270 mOhm Max 0806 2015 Metric
