片式电感
22nH Unshielded Wirewound Inductor 500mA 220mOhm Max 0805 2015 Metric
立创商城:
22nH ±5% 220mΩ
得捷:
FIXED IND 22NH 500MA 220MOHM SMD
贸泽:
固定电感器 0805, 22nH , 500mA SRF 2600MHz, 5%
艾睿:
This rf chip LQW2BAS22NJ00L surface mount inductor from Murata is ideal for applications where space is a major influence of circuit design. This SMD inductor has an operating temperature range of -55 °C to 125 °C. Tape and reel packaging will encase this product during shipment, in order to ensure safe delivery and enable quick mounting of components. This product is 2.29 mm long, 1.52 mm tall and 1.73 mm deep. This device utilizes wirewound technology. It has a tolerance of 5%. This SMD inductor has a maximum DC current of 500m A with a maximum resistance of 220m Ohm. Its test frequency is 250M Hz, while its minimum self-resonant frequency is 2.6G Hz. It has an inductance of 22n H.
安富利:
Ind RF Chip Wirewound 22nH 5% 250MHz 55Q-Factor 500mA 0805 Embossed T/R
Verical:
Inductor RF Chip Unshielded Wirewound 0.022uH 5% 250MHz 55Q-Factor Non Magnetic 0.5A 0.22Ohm DCR 0805 T/R
Win Source:
FIXED IND 22NH 500MA 220MOHM SMD / 22 nH Unshielded Wirewound Inductor 500 mA 220mOhm Max 0805 2015 Metric
额定电流 500 mA
容差 ±5 %
电感 0.022 µH
自谐频率 2.6 GHz
产品系列 LQW
电感公差 ±5 %
测试频率 250 MHz
电阻DC) 0.22 Ω
工作温度Max 125 ℃
工作温度Min -55 ℃
电阻DC Max 0.22 Ω
安装方式 Surface Mount
封装 0805
长度 2.09 mm
宽度 1.53 mm
高度 1.52 mm
封装 0805
工作温度 -55℃ ~ 125℃
产品生命周期 Active
包装方式 Tape & Reel TR
最小包装 2000
RoHS标准 RoHS Compliant
含铅标准 Lead Free
