LQH43MN4R7K03L

Murata 1812 LQH43MN 系列线绕电感器线圈贴片式电感器绕在铁氧体磁芯上。 高频率时的质量高。 低直流电阻。 高电流和电感。 ### 表面安装 1812 电感器（扼流圈）

固定器

得捷:
FIXED IND 4.7UH 500MA 400MOHM SM

立创商城:
4.7uH ±10% 500mA 400mΩ

欧时:
### Murata 1812 LQH43MN 系列线绕电感器线圈贴片式电感器绕在铁氧体磁芯上。 高频率时的质量高。 低直流电阻。 高电流和电感。 ### 表面安装 1812 电感器（扼流圈）

艾睿:
Make any circuit look clean and compact using this general purpose chip LQH43MN4R7K03L surface mount inductor from Murata. This SMD inductor has a minimum operating temperature of -40 °C and a maximum of 85 °C. This component will be shipped in tape and reel packaging to allow for effective mounting and safe delivery. Its test frequency is 1M Hz, while its minimum self-resonant frequency is 38M Hz. It has an inductance of 4.7u H. This SMD inductor has a maximum DC current of 500m A with a maximum resistance of 400m Ohm. This product is 4.8 mm long, 2.8 mm tall and 3.4 mm deep. It has a tolerance of 10%. This device is made with wirewound technology.

安富利:
Ind General Purpose Chip Unshielded Wirewound 4.7uH 10% 1MHz 30Q-Factor Ferrite 500mA 1812 Embossed T/R

Chip1Stop:
Inductor General Purpose Chip Unshielded Wirewound 4.7uH 10% 1MHz 30Q-Factor Ferrite 500mA 400mOhm DCR 1812 T/R

Verical:
Inductor RF Chip Unshielded Wirewound 4.7uH 10% 1MHz 30Q-Factor Ferrite 0.5A 0.4Ohm DCR 1812 T/R

儒卓力:
**LQH43MN 4,7uH 500mA 10% WWT **
