LR2010-R04FW

WELWYN  LR2010-R04FW  片式电阻器, 表面贴装, 厚膜, AEC-Q200 LR系列, 0.04 ohm, 200 V, 2010 [5025公制], 1 W, ± 1%

The Welwyn LR series are automotive grade, low value flat chip resistors with conventional orientation. The Resistance range includes E24 decade values from 0.003ohm to 1ohm. LR series has solder plated copper wrap around termination.

.

EIA 1206, 1210, 2512 chip sizes available

.

Automotive grade AEC-Q200 compliant

.

Power rating of 0.5W LF1206, 1W LR2010 and 2W LR2512

.

±1%, ±2% and ±5% tolerance

.

Dielectric withstand for 200V

.

±100ppm/°C, +200ppm/°C, +300ppm/°C, +500ppm/°C and +900ppm/°C TCR values available

.

Operating temperature range -55°C to +150°C
