NXP LFEBS12UBLAB 学生学习套件, MC9S12DG128, S12, 实时调试, 信号Breakout断点针座
The 是一个S12 DG128微控制器st和alone student learning kitS12UB is targeted at teaching the first course in微控制器s at the university level. The套件contains all of the materials needed to learn MC9S12DG128 operation,内嵌型assembly和C programming. The S12UB电路板提供both debug和user circuitry sections. The debug, or 开发工具section, 支持 both D-Bug12和CodeWarrior 调试器s through a serial RS232 接口. The user circuitry, or Target,提供prewired input/output circuitry to learn the DG128微控制器外部设备operation without any hook up. Both CodeWarrior 用于HCS12X special edition,和S12UB distribution disk 软件are provided in the kit. The special edition CodeWarrior is the full集成 开发 environment with a cap on code size 32K bytes和number of 程序files 32. The distribution disk提供twenty one prewritten prelab/labs, twelve Core, five hook up,和four advanced.
- .
- 单块电路板上的调试和目标电路
- .
- 使用后台调试模式BDM进行实时调试
- .
- 提供可移动的少焊点面包板,支持挂钩实验室和电路原型
- .
- 信号接口针座环绕面包电路板
- .
- 少量焊接面包板之下的硬线焊接原型区域
- .
- 地面香蕉插座可接入所有四个角落
- .
- 板载5V全保护电源, 带状态LED
- .
- MC33879 智能MOS SPI 功率芯片
- .
- 两个CAN 2.0 A/B连接器接口
- .
- LIN接口 带线路输入和线路输出连接器
