LM101AJLQMLV

LM101AQML运算放大器 LM101AQML Operational Amplifiers

General Description

The LM101A is a general purpose operational amplifier which features improved performance over industry standards such as the LM709. Advanced processing techniques make possible an order of magnitude reduction in input currents, and a redesign of the biasing circuitry reduces the temperature drift of input current. Improved specifications

include:

• Offset voltage 3 mV maximum over temperature

• Input current 100 nA maximum over temperature

• Offset current 20 nA maximum over temperature

• Guaranteed drift characteristics

• Offsets guaranteed over entire common mode and supply voltage ranges

• Slew rate of 10V/µs as a summing amplifier

Features

Available with radiation guarantee

Offset voltage 3 mV maximum over temperature

Input current 100 nA maximum over temperature

Offset current 20 nA maximum over temperature

Guaranteed drift characteristics

Offsets guaranteed over entire common mode and supply voltage ranges

Slew rate of 10 V/µS as a summing amplifier
