LINEAR TECHNOLOGY LTC3883EUH#PBF 降压控制器, 24V-4.5V电源, 1 MHz, 5.5V/30A输出, QFN-32
Looking for a step up or step down in voltage within a DC circuit, look no further: this synchronous step down DC voltage controller from will adjust the voltage properly. With an output that has a voltage of 0.5 to 5.5 V, this is power management at its best. This DC voltage controller has single output. Its output produces a current of 30 A. This DC voltage controller has an input voltage of 4.5 to 24 V. It has a switching frequency of 1000 kHz. This DC voltage controller has a minimum operating temperature of -40 °C and a maximum of 105 °C.
频率 1 MHz
电源电压DC 4.50V min
输出接口数 1
输入电压DC 24.0 V
输出电压 5.5 V
输出电流 30 A
针脚数 32
输入电压Max 24 V
输入电压Min 4.5 V
工作温度Max 105 ℃
工作温度Min -40 ℃
电源电压 4.5V ~ 24V
电源电压Max 24 V
电源电压Min 4.5 V
输入电压 24 V
安装方式 Surface Mount
引脚数 32
封装 QFN-32
封装 QFN-32
工作温度 -40℃ ~ 105℃
产品生命周期 Active
包装方式 Each
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC标准 No SVHC
REACH SVHC版本 2015/12/17
| 型号/品牌 | 代替类型 | 替代型号对比 |
|---|---|---|
LTC3883EUH#PBF Linear Technology 凌力尔特 | 当前型号 | 当前型号 |
LTC3883IUH#PBF 凌力尔特 | 完全替代 | LTC3883EUH#PBF和LTC3883IUH#PBF的区别 |
LTC3883EUH#TRPBF 凌力尔特 | 类似代替 | LTC3883EUH#PBF和LTC3883EUH#TRPBF的区别 |
