LT3030MPFE#PBF

LINEAR TECHNOLOGY  LT3030MPFE#PBF  芯片, 稳压器, LDO, 双路, 1.8-20V, 0.3VD, 1.2V, 20TSSOP

Control the voltage level of your circuit with this LDO linear regulator from . Its typical dropout voltage at current is 0.13@10mA|0.17@100mA|0.27@500mA|0.3@750mA|0.14@10mA|0.18@50mA|0.22@100mA|0.3@250mA V. This voltage regulation device"s 2 outputs can produce a current up to 0.75|0.25 A. By only needing an input voltage of 1.8 V with a maximum of 20 V, this is the best way to control the power in your circuit. With an adjustable output that has a voltage of 1.22 to 19.5 V, this is power management at its best. Users like the load regulation of 6mV and line regulation of 5mV. The maximum dropout voltage is 0.2@10mA|0.23@100mA|0.32@500mA|0.36@750mA|0.2@10mA|0.24@50mA|0.28@100mA|0.36@250mA V. This voltage regulation device has a minimum operating temperature of -55 °C and a maximum of 150 °C. Its polarity is positive.
