LP3853ES-1.8

具有电源正常指示和使能功能的 3A、7V、超低压降稳压器 5-DDPAK/TO-263 -40 to 125

PMIC - 稳压器 - 线性 正 固定 1 输出 3A DDPAK/TO-263-5

得捷:
IC REG LIN 1.8V 3A DDPAK/TO263-5

立创商城:
正 Vin=7V Vout=1.8V 3A

贸泽:
LDO Voltage Regulators R 926-3853ES-1.8/NOPB

艾睿:
Never worry about components not turning off and on due to lack of voltage with this LDO LP3853ES-1.8 linear regulator from Texas Instruments. It has an overall accuracy of ±1.5 %. Its typical dropout voltage at current is 0.039@300mA|0.39@3A V. This voltage regulation device&s;s single output can produce a current up to 3 A. This will operate at a minimum voltage of 2.5 V and a maximum voltage of 7 V, making it easy to control the power in your circuit. With a fixed output that has a voltage of 1.8 V, this is power management at its best. At a load regulation of 0.08%Typ and line regulation of 0.02%Typ your circuit is capable of maintaining a constant voltage level at your output. In order to ensure parts aren&s;t damaged by bulk packaging, this product comes in tube packaging to add a little more protection by storing the loose parts in an outer tube. This voltage regulation device has a minimum operating temperature of -40 °C and a maximum of 125 °C. The maximum dropout voltage is 0.05@300mA|0.45@3A V. Its polarity is positive.

Chip1Stop:
LDO Regulator Pos 1.8V 3A 6-Pin5+Tab TO-263 Rail

Verical:
LDO Regulator Pos 1.8V 3A 6-Pin5+Tab TO-263 Tube

罗切斯特:
LDO Regulator Pos 1.8V 3A 6-Pin5+Tab TO-263 Rail
