LTC3115IDHD-2#PBF

LINEAR TECHNOLOGY  LTC3115IDHD-2#PBF  直流-直流开关同步降压-升压稳压器, 可调, 2.7V-40V输入, 2.7V-40V输出, 2A输出, DFN-16

The is a high voltage monolithic synchronous buck-boost DC-to-DC Converter optimized for applications subject to fast <1ms input voltage transients. With its wide 2.7 to 40V input and output voltage ranges, it is well suited for use in a wide variety of industrial power supplies. A proprietary low noise switching algorithm optimizes efficiency with input voltages that are above, below or even equal to the output voltage and ensures seamless transitions between operational modes. Programmable frequency PWM mode operation provides low noise, high efficiency operation and the ability to synchronize switching to an external clock. Switching frequencies up to 2MHz are supported to allow use of small value inductors for miniaturization of the application circuit. Pin selectable Burst Mode® operation reduces standby current and improves light load efficiency which, combined with a 3µA shutdown current, make the LTC3115-2 ideally suited for battery-powered applications.

.

Output disconnect in shutdown, short-circuit protection and internal soft-start

.

Ultralow noise buck-boost PWM

.

Programmable input undervoltage lockout

.

Synchronizable up to 2MHz with an external clock

.

Up to 95% efficiency

.

0.8A Output current for VIN>=3.6V, VOUT=5V

.

30µA No-load quiescent current in Burst Mode® operation
