LT3503EDCB#PBF

LINEAR TECHNOLOGY  LT3503EDCB#PBF  直流-直流开关降压逐步递减稳压器, 可调, 3.6V-20V输入, 780mV-17V输出, 1A输出, DFN-6

The is a current-mode PWM step-down DC-to-DC Converter with an internal 1.45A power switch. The wide operating input range of 3.6 to 20V makes the LT3503 ideal for regulating power from a wide variety of sources. Its high operating frequency allows the use of tiny, inductors and ceramic capacitors, resulting in low, predictable output ripple. Cycle-by-cycle current limit provides protection against shorted outputs and soft-start eliminates input current surge during start-up. The low current <2µA shutdown mode provides output disconnect, enabling easy power management in battery-powered systems.

.

Short-circuit robust

.

Soft-start function

.

Internally compensated

.

5V at 1.2A from 11V to 18V Input

.

5V at 1A from 7.2V to 18V Input

.

3.3V at 1.2A from 8.5V to 12V Input

.

3.3V at 1A from 5.5V to 12V Input

.

400mV at 1A Low VCESAT switch
