LQW15AN27NG00D

MURATA  LQW15AN27NG00D  表面贴装高频电感器, LQW15A_00系列, 27 nH, ± 2%, 0402 [1005 公制], 3.5 GHz, 0.52 ohm

固定器

得捷:
FIXED IND 27NH 280MA 520MOHM SMD

立创商城:
27nH ±2% 520mΩ

欧时:
Murata LQW15A 系列 铁氧体芯材 27 nH 绕线贴片电感器 LQW15AN27NG00D, ±2%容差, 280mA Idc Q:25

e络盟:
高频电感器, 27 nH, LQW15A_00系列, 280 mA, 0402 [1005 公制], 绕线, 0.52 ohm

艾睿:
Make any circuit look clean and compact using this rf chip LQW15AN27NG00D surface mount inductor from Murata. This SMD inductor has an operating temperature range of -55 °C to 125 °C. This product will be shipped in tape and reel packaging so that components can be mounted effectively. This device utilizes wirewound technology. It has an inductance of 27n H. It has a tolerance of 2%. Its test frequency is 100M Hz, while its minimum self-resonant frequency is 3.5G Hz. This product is 1.1 mm long, 0.6 mm tall and 0.6 mm deep. This SMD inductor has a maximum DC current of 280m A with a maximum resistance of 520m Ohm.

安富利:
Ind RF Chip Wirewound 27nH 2% 100MHz 25Q-Factor 280mA 0402 Paper T/R

Chip1Stop:
Inductor RF Chip Unshielded Wirewound 27nH 2% 100MHz 25Q-Factor Ceramic 280mA 520mOhm DCR 0402 T/R

Verical:
Inductor RF Chip Unshielded Wirewound 0.027uH 2% 100MHz 25Q-Factor Non Magnetic 0.28A 0.52Ohm DCR 0402 T/R

Newark:
# MURATA  LQW15AN27NG00D  Surface Mount High Frequency Inductor, LQW15A_00 Series, 27 nH, 280 mA, 0402 [1005 Metric]

儒卓力:
**LQW15A 0,027µH 280mA 2% WWT **

Win Source:
27nH Unshielded Wirewound Inductor 280mA 520 mOhm Max 0402 1005 Metric
