LQH44PN1R0NP0L

MURATA  LQH44PN1R0NP0L  表面贴装高频电感器, LQH44P_P0系列, 1 µH, ± 30%, 1515, 90 MHz, 0.03 ohm

固定器

得捷:
FIXED IND 1UH 2.45A 36 MOHM SMD

欧时:
Murata LQH44P_P0 系列 屏蔽 1 μH 绕线贴片电感器 LQH44PN1R0NP0L, ±30%容差, 2.95A Idc

立创商城:
1uH ±30% 2.45A 36mΩ

e络盟:
高频电感器, 1 µH, LQH44P_P0系列, 2.95 A, 1515, 绕线, 0.03 ohm

艾睿:
Use this power chip LQH44PN1R0NP0L surface mount inductor from Murata to make any circuit look clean and compact. This SMD inductor has a minimum operating temperature of -40 °C and a maximum of 125 °C. This product will be shipped in tape and reel packaging for quick mounting and safe delivery. It has an inductance of 1u H. This SMD inductor has a maximum DC current of 2.45 A with a maximum resistance of 36m Ohm. This device is made with wirewound technology. This product is 4.2 mm long, 1.8 mm tall and 4.2 mm deep. Its test frequency is 1M Hz, while its minimum self-resonant frequency is 90M Hz.

安富利:
Ind Power Chip Shielded Wirewound 1uH 30% 100KHz Ferrite 2.45A 1515 Embossed T/R

Chip1Stop:
Inductor Power Chip Shielded Wirewound 1uH 30% 1MHz Ferrite 2.45A 36mOhm DCR 1515 T/R

TME:
Inductor: wire; SMD; 1515; 1uH; 2450mA; 30mΩ; 4x4x1.65mm; ±30%

Verical:
Inductor Power Chip Shielded Wirewound 1uH 30% 1MHz Ferrite 2.45A 0.036Ohm DCR 1515 T/R

Newark:
# MURATA  LQH44PN1R0NP0L  Surface Mount High Frequency Inductor, LQH44P_P0 Series, 1 µH, 2.95 A, 1515, Wirewound, 0.03 ohm

儒卓力:
**LQH44P 1uH 2450mA 30% WWT **

Win Source:
1μH Shielded Wirewound Inductor 2.45A 36 mOhm Max Nonstandard
