LQW31HN56NJ03L

MURATA  LQW31HN56NJ03L  表面贴装高频电感器, LQW31H系列, 56 nH, ± 5%, 1206 [3216 公制], 1 GHz, 0.14 ohm

Murata 1206 LQW31H 系列磁性屏蔽线绕器

SMD 电感器，用于高频率线绕。

### SMT 1206 电感器（扼流圈）

得捷:
FIXED IND 56NH 330MA 140MOHM SMD

立创商城:
56nH ±5% 140mΩ

欧时:
Murata LQW31H 系列 铁氧体芯材 56 nH 绕线贴片电感器 LQW31HN56NJ03L, ±5%容差, 330mA Idc Q:60

e络盟:
MURATA  LQW31HN56NJ03L  表面贴装高频电感器, LQW31H系列, 56 nH, ± 5%, 1206 [3216 公制], 1 GHz, 0.14 ohm

艾睿:
This rf chip LQW31HN56NJ03L surface mount inductor from Murata is available in all standard chip sizes in multilayer thick film and thin film deposition and wire wound styles. This SMD inductor has a minimum operating temperature of -40 °C and a maximum of 85 °C. In order to guarantee safe delivery and allow for quick mounting of this component after delivery, it will be enclosed in tape and reel packaging during shipment. This SMD inductor has a maximum DC current of 330m A with a maximum resistance of 140m Ohm. This device is made with wirewound technology. Its test frequency is 100M Hz, while its minimum self-resonant frequency is 1G Hz. It has an inductance of 56n H. This product is 3.5 mm long, 2 mm tall and 1.8 mm deep. It has a tolerance of 5%.

安富利:
Ind RF Chip Wirewound 56nH 5% 100MHz 60Q-Factor 330mA 1206 Embossed T/R

Chip1Stop:
Inductor RF Chip Wirewound 56nH 5% 100MHz 60Q-Factor 330mA 140mOhm DCR 1206 T/R

Verical:
Inductor RF Chip Unshielded Wirewound 0.056uH 5% 100MHz 60Q-Factor Non Magnetic 0.33A 0.196Ohm DCR 1206 T/R

Newark:
# MURATA  LQW31HN56NJ03L  Surface Mount High Frequency Inductor, LQW31H Series, 56 nH, 330 mA, 1206 [3216 Metric], Wirewound
