LQW15AN4N7B00D

MURATA  LQW15AN4N7B00D  表面贴装高频电感器, LQW15AN系列, 4.7 nH, ± 0.1nH, 0402 [1005 公制], 8 GHz, 0.07 ohm

固定器

得捷:
FIXED IND 4.7NH 750MA 70MOHM SMD

欧时:
Inductor RF SMD 0402 wirewound 4.7nH

立创商城:
4.7nH ±0.1nH 70mΩ

贸泽:
Fixed Inductors 4.7 NH +-.1NH

艾睿:
Save valuable space on a PCB with this rf chip LQW15AN4N7B00D surface mount inductor from Murata. This SMD inductor has a minimum operating temperature of -55 °C and a maximum of 125 °C. This component will be shipped in tape and reel packaging for effective mounting and safe delivery. This device is made with wirewound technology. Its test frequency is 100M Hz, while its minimum self-resonant frequency is 8G Hz. This SMD inductor has a maximum DC current of 750m A with a maximum resistance of 70m Ohm. This product is 1.1 mm long, 0.6 mm tall and 0.7 mm deep. It has an inductance of 4.7n H.

安富利:
Ind RF Chip Wirewound 4.7nH 0.1nH 100MHz 25Q-Factor 750mA 0402 Paper T/R

Chip1Stop:
Inductor RF Chip Wirewound 4.7nH 0.1nH 100MHz 25Q-Factor 750mA 70mOhm DCR 0402 Paper T/R

Verical:
Inductor RF Chip Unshielded Wirewound 0.0047uH 0.1nH 100MHz 25Q-Factor Non Magnetic 0.75A 0.07Ohm DCR 0402 T/R

Newark:
# MURATA  LQW15AN4N7B00D  Surface Mount High Frequency Inductor, LQW15AN Series, 4.7 nH, 0.1nH, 0402 [1005 Metric], 8 GHz

儒卓力:
**LQW15A 0,0047µH 750mA 0,1nH WWT **

Win Source:
4.7nH Unshielded Wirewound Inductor 750mA 70 mOhm Max 0402 1005 Metric
