LPC2220FET144/G

NXP  LPC2220FET144/G  微控制器, 32位, ARM7TDMI, 75 MHz, 64 KB, 144 引脚, TFBGA

The is a flashless 16-/32-bit Microcontroller based on ARM7TDMI-S CPU with real-time emulation and embedded trace support. For critical code size applications, the alternative 16-bit Thumb mode reduces code by more than 30 % with minimal performance penalty. The device incorporates 16kB on-chip SRAM, 8-channel 10-bit A/D converter, three 32-bit timers, PWM channels, up to nine external interrupt pins and 76 general-purpose I/O pins.

.

Serial bootloader using UART0 provides in-system download and programming capabilities

.

EmbeddedICE-RT and Embedded Trace interfaces offer real-time debugging

.

Two 32-bit timers, PWM unit, real-time clock and watchdog

.

Multiple serial interfaces including two UARTs 16C550, fast I2C-bus 400 Kbit/s and two SPIs

.

Vectored interrupt controller with configurable priorities and vector addresses

.

Configurable external memory interface w/up to 4 banks, each up to 16MB and 8/16/32-bit data width

.

Up to 76 general purpose pins 5V tolerant capable

.

Up to nine edge/level sensitive external interrupt pins available

.

75MHz Maximum CPU clock available from programmable on-chip PLL

.

On-chip crystal oscillator with an operating range of 1MHz to 25MHz

.

Power saving modes include Idle and power-down

.

Processor wake-up from power-down mode via external interrupt

.

Individual enable/disable of peripheral functions for power optimization
