LQW15AN4N7C00D

MURATA  LQW15AN4N7C00D  表面贴装高频电感器, LQW15A_00系列, 4.7 nH, ± 0.2nH, 0402 [1005 公制], 8 GHz, 0.07 ohm

固定器

得捷:
FIXED IND 4.7NH 750MA 70MOHM SMD

立创商城:
4.7nH ±0.2nH 70mΩ

欧时:
Murata LQW15A 系列 铁氧体芯材 4.7 nH 绕线贴片电感器 LQW15AN4N7C00D, ±0.2nH容差, 750mA Idc Q:25

e络盟:
MURATA  LQW15AN4N7C00D  表面贴装高频电感器, LQW15A_00系列, 4.7 nH, ± 0.2nH, 0402 [1005 公制], 8 GHz, 0.07 ohm

艾睿:
This rf chip LQW15AN4N7C00D surface mount inductor from Murata is placed on the surface of a PCB during surface mount manufacturing processing. This SMD inductor has an operating temperature range of -55 °C to 125 °C. This product will be shipped in tape and reel packaging for quick mounting and safe delivery. This SMD inductor has a maximum DC current of 750m A with a maximum resistance of 70m Ohm. This device utilizes wirewound technology. This product is 1.1 mm long, 0.6 mm tall and 0.7 mm deep. It has an inductance of 4.7n H. Its test frequency is 100M Hz, while its minimum self-resonant frequency is 8G Hz.

安富利:
Ind RF Chip Wirewound 4.7nH 0.2nH 100MHz 25Q-Factor 750mA 0402 Paper T/R

Chip1Stop:
Inductor RF Chip Wirewound 4.7nH 0.2nH 100MHz 25Q-Factor 750mA 70mOhm DCR 0402 T/R

Verical:
Inductor RF Chip Unshielded Wirewound 0.0047uH 0.2nH 100MHz 25Q-Factor Non Magnetic 0.75A 0.07Ohm DCR 0402 T/R

儒卓力:
**LQW15A 0,0047µH 750mA 0,2nH WWT **

Win Source:
4.7nH Unshielded Wirewound Inductor 750mA 70 mOhm Max 0402 1005 Metric
