100 W 低成本 双输出 5 V / 12 V 内部 AC/DC 开关电源
Switch, Rugged PCB Type, 15 A Typ. Incrush Current, 0.75 mA Max. Leakage Current
** Open Frame, Universal Input 85~264 with Power Factor Correction.**
* High Quality: Documented Field Failure Rate, Less Than 0.012%
* 5 and 12, 5 and 24 Volt Outputs
* Universal Input: 85~264 Volts AC
* Low 5 High 12, 24 Volt Output Capacity
* Active Power Factor Correction
* Peak Current Capability 12, 24 Volt Outputs
* Low Profile LEB100, LEB150 Fits 1U High, LEB225 1.65" High
* Additional 3 and 4 Channel Outputs Available
* No Minimum Current
* Fully Isolated and Independent Outputs
* Overvoltage, Overcurrent, Thermal and Peak Current Protection
* UL, C-UL, TÜV Safety Approvals and CE
* Two-Year Warranty
频率 833 mHz
额定功率 100 W
输出接口数 2
输出电流 5 A
输出功率 85 W
隔离电压 3 kV
输入电压DC Max 370 V
输入电压DC Min 120 V
输入电压AC Max 264 V
输入电压AC Min 85 V
输出电流Max 5A, 10A
输入电流Min 1.2 A
工作温度Max 70 ℃
工作温度Min -10 ℃
输入电压 85V ~ 264V
引脚数 11
长度 8.74 in
宽度 2.96 in
高度 1.38 in
工作温度 -10℃ ~ 70℃
产品生命周期 Active
包装方式 Bulk
制造应用 ITE（商业）
RoHS标准 RoHS Compliant
含铅标准 Lead Free
