ARTESYN EMBEDDED TECHNOLOGIES LCB100N AC-DC Enclosed Power Supply, Adjustable, Fixed, 1Outputs, 88V, 264V, 105W, 15V
Safely convert alternating currents into direct currents that your electronic devices can make use of with this AC to DC power supply from Artesyn Embedded Power. It has a voltage of 15 V and maximum output power of 105 W. This part"s single output can handle a current up to 7 A. This part has a temperature range of -25 °C to 70 °C.
得捷:
AC/DC CONVERTER 15V 100W
贸泽:
Switching Power Supplies 105W 15V 7A
艾睿:
Safely convert alternating currents into direct currents that your electronic devices can make use of with this LCB100N AC to DC power supply from Artesyn Embedded Power. It has a voltage of 15 V and maximum output power of 105 W. This part&s;s single output can handle a current up to 7 A. This part has a temperature range of -25 °C to 70 °C.
安富利:
AC/DC Power Supply Single-OUT 15V 7A 105W
Verical:
AC/DC Power Supply Single-OUT 15V 7A 105W 5-Pin
Newark:
# ARTESYN EMBEDDED TECHNOLOGIES LCB100N AC/DC Enclosed Power Supply, Adjustable, Fixed, 1 Outputs, 88 V, 264 V, 105 W, 15 V
额定功率 100 W
输出接口数 1
输出电压 15 V
输出电流 7 A
输出功率 105 W
隔离电压 3 kV
输入电压DC Max 373 V
输入电压DC Min 125 V
输入电压AC Max 264 v
输入电压AC Min 88 v
输出电流Max 7 A
输入电流Min 2.5 A
输出功率Max 105 W
工作温度Max 70 ℃
工作温度Min -25 ℃
输入电压 88VAC ~ 264VAC
安装方式 Chassis
引脚数 5
长度 129.5 mm
宽度 97.5 mm
高度 37.5 mm
工作温度 -25℃ ~ 70℃
产品生命周期 Active
包装方式 Cut Tape CT
RoHS标准 RoHS Compliant
含铅标准 Lead Free
ECCN代码 EAR99
