LQW18AN39NG00D

0603

固定器

得捷:
FIXED IND 39NH 400MA 260MOHM SMD

立创商城:
39nH ±2% 260mΩ

欧时:
### Murata 0603 LQW18AN 系列线绕电感器高质量线圈电感器，设计用于 VHF 和 UHF 应用。 高谐振频率。 低容差电感值。 带有后缀 "10D" 的型号具有较低直流电阻值。 **应用：**高频率电路，用于无线电信设备：例如蓝牙、GSM、W-LAN。 ![http://china.rs-online.com/largeimages/L0109217-10.jpg]http://china.rs-online.com/largeimages/L0109217-10.jpg ### SMT 0603 电感器（扼流圈）

贸泽:
Fixed Inductors 39 NH 2%

艾睿:
This rf chip LQW18AN39NG00D surface mount inductor from Murata is ideal for applications where space is a major influence of circuit design. This SMD inductor has an operating temperature range of -55 °C to 125 °C. This component will be shipped in tape and reel packaging to allow for effective mounting and safe delivery. This SMD inductor has a maximum DC current of 400m A with a maximum resistance of 260m Ohm. This device utilizes wirewound technology. It has an inductance of 39n H. This product is 1.8 mm long, 1 mm tall and 1 mm deep. It has a tolerance of 2%. Its test frequency is 100M Hz, while its minimum self-resonant frequency is 2.8G Hz.

安富利:
Ind RF Chip Wirewound 39nH 2% 100MHz 40Q-Factor 400mA 0603 Paper T/R

Chip1Stop:
Inductor RF Chip Wirewound 39nH 2% 100MHz 40Q-Factor 400mA 260mOhm DCR 0603 T/R

Verical:
Inductor RF Chip Unshielded Wirewound 0.039uH 2% 100MHz 40Q-Factor Non Magnetic 0.4A 0.26Ohm DCR 0603 T/R

儒卓力:
**LQW18AN 39nH 400mA 2% WWT **

Win Source:
FIXED IND 39NH 400MA 260 MOHM
