0508 0.22 µF 10 V 10 % 容差 X7R SMD 单片 陶瓷电容 高CV
0.22µF ±20% 10V Ceramic Capacitor X7R 0805 2012 Metric
得捷:
CAP CER 0.22UF 10V X7R 0805
立创商城:
220nF ±20% 10V
艾睿:
Available with a variety of capacitance values, voltage ratings, package sizes, and other parameters, this LLA215R71A224MA14L multilayer ceramic capacitor from Murata can be used in multiple applications and for various purposes. It can withstand a voltage of 10 VDC. This MLCC capacitor has a maximum operating temperature of 125 °C. This product will be shipped in tape and reel packaging so that components can be mounted effectively. It has a tolerance of 20%. Its capacitance value is 0.22uF. This product is 2 mm long, 0.5 mm tall and 1.25 mm deep.
Chip1Stop:
Cap Ceramic 0.22uF 10V X7R 20% SMD 0805 125℃ Embossed T/R
额定电压DC 10.0 V
电容 220000 pF
容差 ±20 %
电介质特性 X7R
产品系列 LLA
工作温度Max 125 ℃
工作温度Min -55 ℃
额定电压 10 V
安装方式 Surface Mount
封装公制 2012
封装 0805
长度 2 mm
宽度 1.25 mm
高度 0.5 mm
封装公制 2012
封装 0805
厚度 0.5 mm
材质 X7R/-55℃~+125℃
工作温度 -55℃ ~ 125℃
产品生命周期 Active
包装方式 Tape & Reel TR
最小包装 4000
制造应用 旁通,去耦
RoHS标准 RoHS Compliant
含铅标准 Lead Free
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
LLA215R71A224MA14L muRata 村田 | 当前型号 | 当前型号 |
LLM215R70J224MA11L 村田 | 功能相似 | LLA215R71A224MA14L和LLM215R70J224MA11L的区别 |
