LQM18PN1R0MFRL

0603

固定器

得捷:
FIXED IND 1UH 950MA 250 MOHM SMD

立创商城:
1uH ±20% 200mΩ

贸泽:
Fixed Inductors 0603 1.0uH 20%

艾睿:
This power chip LQM18PN1R0MFRL surface mount inductor from Murata is placed on the surface of a PCB during surface mount manufacturing processing. This SMD inductor has a minimum operating temperature of -40 °C and a maximum of 85 °C. This component will be shipped in tape and reel packaging for effective mounting and safe delivery. It has an inductance of 1u H. It has a tolerance of 20%. Its test frequency is 1M Hz, while its minimum self-resonant frequency is 100M Hz. This product is 1.75 mm long, 0.95 mm tall and 0.95 mm deep. This device is made with multi-layer technology. This SMD inductor has a maximum DC current of 950m A with a maximum resistance of 250m Ohm.

安富利:
Ind Power Chip Shielded Multi-Layer 1uH 20% 1MHz Ferrite 950mA 0603 Embossed T/R

Chip1Stop:
Inductor Power Chip Shielded Multi-Layer 1uH 20% 1MHz Ferrite 950mA 250mOhm DCR 0603 T/R

Verical:
Inductor Power Chip Shielded Multi-Layer 1uH 20% 1MHz Ferrite 0.95A 0.25Ohm DCR 0603 T/R

儒卓力:
**LQM18PN 1uH 950mA 20% MLT **
