0603
固定器
得捷:
FIXED IND 3.3UH 700MA 438MOHM SM
立创商城:
3.3uH ±20% 437.5mΩ
艾睿:
Does your electronic circuit design require filtering, power supplies, and other similar functions? Then this power chip LQM18PN3R3MFRL surface mount inductor from Murata is perfect for you! This SMD inductor has a minimum operating temperature of -40 °C and a maximum of 85 °C. This component will be shipped in tape and reel packaging to allow for effective mounting and safe delivery. It has a tolerance of 20%. This product is 1.75 mm long, 0.95 mm tall and 0.95 mm deep. This SMD inductor has a maximum DC current of 700m A with a maximum resistance of 438m Ohm. Its test frequency is 1M Hz, while its minimum self-resonant frequency is 60M Hz. It has an inductance of 3.3u H. This device is made with multi-layer technology.
安富利:
Ind Power Chip Shielded Multi-Layer 3.3uH 20% 1MHz Ferrite 700mA 0603 Embossed T/R
Verical:
Inductor Power Chip Shielded Multi-Layer 3.3uH 20% 1MHz Ferrite 0.7A 0.438Ohm DCR 0603 T/R
额定电流 700 mA
容差 ±20 %
电感 3.3 µH
自谐频率 60 MHz
产品系列 LQM
电感公差 ±20 %
测试频率 1 MHz
电阻DC) ≤438 mΩ
工作温度Max 85 ℃
工作温度Min -40 ℃
精度 ±20 %
电阻DC Max 0.438 Ω
安装方式 Surface Mount
封装公制 1608
封装 0603
长度 1.6 mm
宽度 0.8 mm
高度 0.95 mm
封装公制 1608
封装 0603
工作温度 -40℃ ~ 85℃
产品生命周期 Active
包装方式 Tape & Reel TR
最小包装 4000
RoHS标准 RoHS Compliant
含铅标准 无铅
