0603
固定器
得捷:
FIXED IND 4.3NH 850MA 59MOHM SMD
欧时:
Murata LQW18A 系列 铁氧体芯材 4.3 nH 绕线贴片电感器 LQW18AN4N3D00D, ±0.5nH容差, 850mA Idc Q:35
立创商城:
4.3nH ±0.5nH 59mΩ
贸泽:
Fixed Inductors 4.3 NH +-.5NH
艾睿:
This rf chip LQW18AN4N3D00D surface mount inductor from Murata is ideal for saving valuable space on a PCB. This SMD inductor has a minimum operating temperature of -55 °C and a maximum of 125 °C. This component will be shipped in tape and reel packaging for effective mounting and safe delivery. This SMD inductor has a maximum DC current of 850m A with a maximum resistance of 59m Ohm. Its test frequency is 100M Hz, while its minimum self-resonant frequency is 6G Hz. This device is made with wirewound technology. It has an inductance of 4.3n H. This product is 1.8 mm long, 1 mm tall and 1 mm deep.
安富利:
Ind RF Chip Wirewound 4.3nH 0.5nH 100MHz 35Q-Factor 850mA 0603 Paper T/R
Chip1Stop:
Inductor RF Chip Wirewound 4.3nH 0.5nH 100MHz 35Q-Factor 850mA 59mOhm DCR 0603 Paper T/R
Verical:
Inductor RF Chip Unshielded Wirewound 0.0043uH 0.5nH 100MHz 35Q-Factor Non Magnetic 0.85A 0.059Ohm DCR 0603 T/R
Win Source:
4.3nH Unshielded Wirewound Inductor 850mA 59 mOhm Max 0603 1608 Metric
额定电流 850 mA
电感 4.3 nH
自谐频率 6 GHz
产品系列 LQW
屏蔽 No
电感公差 ±0.5 nH
测试频率 100 MHz
电阻DC) ≤59 mΩ
工作温度Max 125 ℃
工作温度Min -55 ℃
电阻DC Max 59 mΩ
安装方式 Surface Mount
封装公制 1608
封装 0603
长度 1.6 mm
宽度 0.8 mm
高度 0.8 mm
封装公制 1608
封装 0603
工作温度 -55℃ ~ 125℃
产品生命周期 Active
包装方式 Tape & Reel TR
最小包装 4000
RoHS标准 RoHS Compliant
含铅标准 Lead Free
