LE50ABZ-AP

LDO（低压降）线性电压稳压器，STMicroelectronics，高达 100mA### LDO（低压降）线性电压调节器，STMicroelectronics低压降或 LDO 为线性电压稳压器。 我们有多种系列的线性稳压器。 LDO 稳压器可在输入 - 输出差分电压较小时运行。 LDO 电压稳压器可提供快速瞬态响应、宽输入电压范围、低静态电流、低噪声、高 PSRR。

LDO（低压降）线性电压稳压器，STMicroelectronics，高达 100mA

欧时:
STMicroelectronics LE50ABZ-AP LDO 稳压器, 5 V输出, 100mA最大输出, ±1%精确度, 3引脚 TO-92封装

得捷:
IC REG LINEAR 5V 100MA TO92-3

艾睿:
Control the voltage level of your circuit with this LDO LE50ABZ-AP linear regulator from STMicroelectronics. Its typical dropout voltage at current is 0.2@100mA V. It has an overall accuracy of ±1 %. This voltage regulation device&s;s single output can produce a current up to 0.1 A. Use this part at voltages lower than 18 V. With a fixed output that has a voltage of 5 V, this is power management at its best. Maintain a constant voltage level with a load regulation of 15mV and line regulation of 20mV. Its polarity is positive. The maximum dropout voltage is 0.4@100mA V. This voltage regulation device has an operating temperature range of -40 °C to 125 °C.

安富利:
LDO Regulator Pos 5V 0.1A 3-Pin TO-92 Ammo

Verical:
LDO Regulator Pos 5V 0.1A 3-Pin TO-92 T/R

Newark:
# STMICROELECTRONICS  LE50ABZ-AP  Fixed LDO Voltage Regulator, 7V to 18V, 200mV Dropout, 5Vout, 350mAout, TO-92-3

DeviceMart:
IC REG LDO 5V .1A TO-92
